Plastic chair making injection molding machine SLA758 Wholesale

Home / Product / Special injection molding machine / Plastic chair making injection molding machine / Plastic chair making injection molding machine SLA758

Plastic chair making injection molding machine SLA758


SLA758
Plastic chair making injection molding machine SLA758
  • Plastic chair making injection molding machine SLA758
  • Plastic chair making injection molding machine SLA758
  • Plastic chair making injection molding machine SLA758
  • Plastic chair making injection molding machine SLA758

Plastic chair making injection molding machine SLA758 Details

MACHINE MODEL SLA758
INJECTION UNIT  A B C D
SCREW DIAMETER (MM) 90 95 105 110
SCREW L/D RATIO (L/D) 23.2 22.2 19.9 19
INJECTION PRESSURE(Mpa) 195 175 143 130
SHOT VOLUME(CM³) 2926 3260 3983 4371
INJECTION WEIGHT (G) 2583 2878 3515 3858
INJECTION RATE(CM³/S) 593 661 808 887
SCREW SPEED(RPM) 108
INJECTION STROKE(MM) 460
CLAMPING UNIT
CLAMPING FORCE(KN) 7580
TOGGLE STROKE(MM) 950
SPACE BETWEEN TIE-BARS(MM) 980X950
MAX.MOLD HEIGHT(MM) 960
MIN.MOLD HEIGHT(MM) 400
EJECTOR STROKE(MM) 280
EJECTOR TONNAGE(KN) 210
OTHERS
MAX.PUMP PRESSURE(Mpa) 16
SERVO MOTOR POWER(KW) 37+30
HEATER POWER(KW) 54.5
HEATING SECTION(part) 4+1
OILTANK CUBAGE(L) 1260
MACHINE DIMENSIONS(M) 11.42X2.4X3.14
MACHINE WEIGHT(T) 40.2
Trustworthy operational system which to fulfill every demand

This system features high stability and highresponse speed,using colorful LCD. Easyoperation of man- machine interface, also ithas a number of peripheral interfaces.
Control system applies all digital computer special controller, with multiple CPU division processing.It has multi-function automatic fault detection and alarm system. It capable to storage99 sets moulds processing procedure. Equip with remote control interface.This system featureshigh stability and high response speed, using colorful LCD.Easy operation of man- machineinterface, also it has a number of peripheral interfaces."

STABLE AND RELIABLE OFELECTRIC CONTROLSYSTEM

Control system applices all digital computer special controller, with multiple CPU division processing.
1.strong function and easy operation
2.High quality electrical elements,enhanced
3.hardware circuits, strong anti-interference ability,Stable and reliable of electric control system reliable running and high stability.

HIGH STABILITY,ACCURACY AND HIGH REPEATABILITYINJECTION UNIT

Six zone injection and five zone pressure protection areseparately controlled by precise linear transducer andtime control.Each zone action pressure and speed canbe setting as demand. It features stable injection andaccurate pressure protection,high repeatability. Theresidual stress of molded products is stable andconsistent.

Using world famous valves to control injection molding actionsprecisely, make the system performance stability and reliability.

Main hydraulic components, sealing ringsand high pressureflexible hose are worldfamous brands.
Oil distirbute block placed in reasonable way,the system has fast response and excellentdynamic performance.

MOULD PLATEN HIGH RIGIDITY ANDSMOOTH MOVEMENT

1.Oblique arranged double toggle mechanical mould clamping unit
2.Mould cooling water distributor
3.Low pressure mould protection device
4.cores installation standard interface
5.Multi-zone mould open& close pressure, speed and position control
6.Automatic centralized lubrication system
7.Multi type hydraulic ejector modes
8.Linear transducer control mould open& close and ejector
9.Fast speed mould close pressure differential device
10.Auto mould thickness adjustment (optional)
