PET preform hydraulic injection molding machine strawberry basket plastic fruit basket SLA1680


SLA1680
PET preform hydraulic injection molding machine strawberry basket plastic fruit basket SLA1680
  • PET preform hydraulic injection molding machine strawberry basket plastic fruit basket SLA1680
  • PET preform hydraulic injection molding machine strawberry basket plastic fruit basket SLA1680
  • PET preform hydraulic injection molding machine strawberry basket plastic fruit basket SLA1680
  • PET preform hydraulic injection molding machine strawberry basket plastic fruit basket SLA1680

PET preform hydraulic injection molding machine strawberry basket plastic fruit basket SLA1680 Details

MACHINE MODEL SLA1680
INJECTION UNIT  A B C D
SCREW DIAMETER (MM) 130 140 150 160
SCREW L/D RATIO (L/D) 23.7 22 20.4 19.3
INJECTION PRESSURE(Mpa) 185 160 139 122
SHOT VOLUME(CM³) 9158 10621 12193 13873
INJECTION WEIGHT (G) 8333 9665 11095 12624
INJECTION RATE(CM³/S) 1135 1317 1512 1720
SCREW SPEED(RPM) 90
INJECTION STROKE(MM) 690
CLAMPING UNIT
CLAMPING FORCE(KN) 16800
TOGGLE STROKE(MM) 1600
SPACE BETWEEN TIE-BARS(MM) 1560X1480
MAX.MOLD HEIGHT(MM) 1600
MIN.MOLD HEIGHT(MM) 700
EJECTOR STROKE(MM) 400
EJECTOR TONNAGE(KN) 350
OTHERS
MAX.PUMP PRESSURE(Mpa) 17.5
SERVO MOTOR POWER(KW) 41+41+41+41
HEATER POWER(KW) 98.4
HEATING SECTION(part) 6+1
OILTANK CUBAGE(L) 2500
MACHINE DIMENSIONS(M) 15.8X3.30X3.60
MACHINE WEIGHT(T) 105
Trustworthy operational system which to fulfill every demand

This system features high stability and highresponse speed,using colorful LCD. Easyoperation of man- machine interface, also ithas a number of peripheral interfaces.
Control system applies all digital computer special controller, with multiple CPU division processing.It has multi-function automatic fault detection and alarm system. It capable to storage99 sets moulds processing procedure. Equip with remote control interface.This system featureshigh stability and high response speed, using colorful LCD.Easy operation of man- machineinterface, also it has a number of peripheral interfaces."

STABLE AND RELIABLE OFELECTRIC CONTROLSYSTEM

Control system applices all digital computer special controller, with multiple CPU division processing.
1.strong function and easy operation
2.High quality electrical elements,enhanced
3.hardware circuits, strong anti-interference ability,Stable and reliable of electric control system reliable running and high stability.

HIGH STABILITY,ACCURACY AND HIGH REPEATABILITYINJECTION UNIT

Six zone injection and five zone pressure protection areseparately controlled by precise linear transducer andtime control.Each zone action pressure and speed canbe setting as demand. It features stable injection andaccurate pressure protection,high repeatability. Theresidual stress of molded products is stable andconsistent.

Using world famous valves to control injection molding actionsprecisely, make the system performance stability and reliability.

Main hydraulic components, sealing ringsand high pressureflexible hose are worldfamous brands.
Oil distirbute block placed in reasonable way,the system has fast response and excellentdynamic performance.

MOULD PLATEN HIGH RIGIDITY ANDSMOOTH MOVEMENT

1.Oblique arranged double toggle mechanical mould clamping unit
2.Mould cooling water distributor
3.Low pressure mould protection device
4.cores installation standard interface
5.Multi-zone mould open& close pressure, speed and position control
6.Automatic centralized lubrication system
7.Multi type hydraulic ejector modes
8.Linear transducer control mould open& close and ejector
9.Fast speed mould close pressure differential device
10.Auto mould thickness adjustment (optional)
